Ruthless Audio 2300.1
Ruthless Audio 2300.1
COMPETITION MONOBLOCK • RATED AT 14.4V
Couldn't load pickup availability
The Ruthless Audio 2300.1 is a compact competition-grade monoblock built to hit hard and stay stable. Rated at 2,300W RMS at 1 ohm, capable of 0.5-ohm operation, and strappable at 1 ohm, it gives daily and competition builders serious wiring flexibility without jumping straight to a giant chassis.
WHY CHOOSE THE RUTHLESS AUDIO 2300.1?
- 2,300W RMS @ 1Ω (14.4V) — strong output for high-excursion subwoofer systems.
- 1,200W RMS @ 2Ω / 600W RMS @ 4Ω — useful power across common wiring configurations.
- 1-Year 0.5Ω Warranty Coverage — Ruthless backs this full-size monoblock down to half ohm when warranty conditions are met.
- Strappable Design — run two 2300.1 amplifiers at a 1-ohm strapped load when the system is designed correctly.
- Included Bass Knob — convenient level control from the driver’s seat.
- Tiffany-Style RCA Inputs — secure, high-quality signal connections.
- 1/0 AWG Power Inputs with a 200A fuse recommendation for serious current delivery.
- 10Hz–250Hz Frequency Response with 0–180° phase control for flexible subwoofer integration.
FULL SPECIFICATIONS
| RMS Power @ 1Ω (14.4V) | 2,300W |
| RMS Power @ 2Ω (14.4V) | 1,200W |
| RMS Power @ 4Ω (14.4V) | 600W |
| Minimum Covered Load | 0.5Ω |
| Strapped Load | 1Ω |
| Channels | 1 (Monoblock) |
| Input Sensitivity | 0.2V–6V |
| Frequency Response | 10Hz–250Hz |
| Phase Control | 0–180° |
| THD | <0.01% @ 4Ω |
| RCA Inputs | Tiffany-style |
| Power Inputs | 1/0 AWG |
| Recommended Fuse | 200A |
| Length | 17 in. |
| Width | 9-1/16 in. |
| Height | 2.75 in. |
| Bass Knob | Included |
ELECTRICAL & INSTALLATION
The 2300.1 still needs real electrical support. Use quality 1/0 AWG OFC power and ground wiring, a solid low-resistance ground, correct fusing, and enough charging/battery reserve to hold voltage under load. A Big 3 upgrade and charging-system improvements may be required depending on the vehicle and how hard the amplifier will be used.
Operation below 11V is not covered under warranty. If you plan to run at 0.5 ohm, treat stable voltage and proper current delivery as part of the amplifier installation.
Calculate the final impedance of the entire subwoofer/voice-coil network before connecting the amp. Wiring below the covered load is not warrantable.
FREQUENTLY ASKED QUESTIONS
Is the 2300.1 covered at 0.5 ohm?
Yes. The standard 1-year manufacturer defect warranty covers operation down to 0.5 ohm when all Ruthless warranty requirements are met.
Can I strap two 2300.1 amplifiers?
Yes. The 2300.1 can be strapped at a 1-ohm final load. Proper wiring, matching gain, signal setup, and electrical support are critical.
Does it include a bass knob?
Yes. A remote bass-level control is included.
Do I need upgraded electrical?
For sustained high-output use, yes. The amount of charging and reserve capacity depends on the vehicle and system, but quality 1/0 AWG wiring and stable voltage are the starting point.
What can void warranty coverage?
Warranty does not cover vibration damage, wire or debris inside the amplifier, wiring below the covered impedance, external RCA damage, excessive clipping, or operation below 11V. Full warranty terms apply.
EXTENDED WARRANTY
No – Standard Warranty (1 Year)
Includes the standard 1-year manufacturer defect warranty, including covered operation down to 0.5 ohm when all warranty requirements are met.
Yes – Extended Warranty (2 Years Total)
Adds 1 additional year of manufacturer defect warranty coverage for 2 years total.
COMPETITION DNA. MORE MANAGEABLE CURRENT.
2,300 WATTS THAT FITS MORE BUILDS.
The Ruthless 2300.1 brings the same competition-oriented approach into a more manageable power class. It is rated at 2,300 watts RMS at 1 ohm, 1,200 watts at 2 ohms and 600 watts at 4 ohms at 14.4 volts, and Ruthless rates it for 0.5-ohm operation per amplifier or 1 ohm when strapped.
The 2300.1 includes a bass knob and uses Tiffany-style RCA inputs, 1/0 power connections, 0.2–6V input sensitivity, 10–250Hz response and 0–180° phase control. It is a strong fit for daily and competition systems that need real output without jumping straight into 4.5K-plus electrical demands.
WHY THIS AMP?
THE REASON IT EXISTS.
Serious monoblock output with 1,200W at 2 ohms and 600W at 4 ohms.
Competition-oriented impedance flexibility with a 1-year 0.5-ohm warranty.
Remote bass control is included for easy level adjustment from the driver seat.
A more compact footprint than the larger Ruthless monoblocks makes install planning easier.
VERIFIED SPECIFICATIONS
THE NUMBERS.
200A FUSE. PLAN ACCORDINGLY.
BASIC ELECTRICAL UPGRADES MAY BE ENOUGH.
Ruthless specifies a 200-amp fuse and recommends electrical upgrades based on the vehicle. At this power level, the right answer depends on factory charging capacity, battery condition, cable size, final impedance and how the system is used.
A healthy charging system and low-resistance power and ground path matter more than buying parts from a generic checklist.
SHOP POWER + GROUND →WARRANTY OPTIONS
STANDARD OR EXTENDED.
The standard product option includes a 1-year manufacturer defect warranty. Where offered on the product, the extended-warranty option adds one additional year for 2 years total coverage. Any special low-impedance warranty requirement shown above still depends on the installation meeting Ruthless requirements.
FINISH THE SYSTEM
MATCH THE REST OF THE BUILD.
Choose the speaker or subwoofer load, electrical support, wire size, fuse protection and signal chain before the install starts. The amplifier performs best when the entire system is designed as one package.
